a4 laser cutting machine

Product Description Specification ITEM MODEL XM301520D Type of the Laser Generator Fiber Laser Working Dielectric YV04 Laser Wavelength 1070nm Rated Power Output 2000W Beam quality ＜0.37mrad X-axis travel 1500mm Y-axis travel 3000mm Z-axis travel 120mm Effective cutting range 1500mm×3000mm Workbench axial positioning accuracy ≤±0.03mm/m Workbench repeat positioning accuracy ≤±0.03mm/m Max. positioning speed 120m/min Power supply rated voltage 380V etc. Frequency 50Hz Workbench Max. bearing capacity 1500KG Phases 3 Main power protection grade IP54 Packing & Delivery Before the shipment, the machine will be coated with antirust oil. The machine is transported by standard container. Inside the container, we will use…

Machine Description Laser cutting is the best cutting method among the various cutting technologies that people have mastered today. The advantages of laser cutting are: small thermal deformation, high cutting accuracy, low noise, no pollution, easy to realize automatic cutting, although the initial investment is large ( Disadvantage), but the processing cost is 50% less than mechanical processing. As an advanced manufacturing technology, laser cutting has the advantages of wide application range, flexible process, high processing precision, good quality, clean production process and easy realization of automation, flexibility, intelligence, and improvement of product quality and labor productivity. Machine Feature 1.…

Production Description The biggest advantages of machine help you choose most suitable one:We cooperate with many brands, the main parts can be optional according to your budget, and the machine body (working table / cover /rotary / exchange platform) can be customized Details Precision Cutting This series coperate with raytools cutting head, The error is less than 0.01mm, you can choose RAYTOOLS/ AU3TECH / WSX / PRECITEC as well, we coperate with top brand to ensure quality. 2t Stable Machine Frame Palte welded machine bed can support heavy material cutting and no deformation within 10 years, and It doesn't shake…

(1) Fiber laser cutting machine is for metal precise cutting powered by fiber laser technology. (2) The efficiency of a fiber laser far exceeds traditional YAG or CO2 laser. The fiber laser beam is capable of cutting reflective metals with much less energy as the laser is absorbed into the metal being cut. Application industry: Metal cutting, electrical switch manufacturing, elevator manufacturing, household electrical appliance manufacturing, cooking utensils, tools machining , such as a variety of machinery manufacturing and processing industry. Application Materials: Fiber Laser Cutting Equipment is suitable for metal cutting like Stainless Steel Sheet, Mild Steel Plate, Carbon…
