large press brake

The CNC press brake uses the mold (general or special mold) to bend a cold metal sheet into a workpiece of various geometric cross-section shapes. It is a sheet metal forming machine designed for cold rolling sheet metal processing. It is widely used in sheet metal bending, such as automobile, aircraft manufacturing, light industry, shipbuilding, container, elevator, railway vehicles and other industries. 1. High bending precision,fast working speed, and efficient,operational safety, performance stably. 2. Good antiknock frame(welded-steel plate construction), whole frame is been tempering, reduce modification, using large-scale CNC milling machine,process in one time, insure high-precision. 3. Using international brand…

Product Description Press Brake Metal Press Brake WC-63T/3200 Metal Sheet Bending Machine Cnc Hydraulic Press Brake Model: KCN-6332 2 Axis CNC Control(X, Y,) X: Backgauge front and back; Y: Ram stroke W: Worktable crowning (optional) Main functions and features 1. Overall welded and processed structure. 2. High mechanical strength and strong rigidity. 3. Ram stroke hydraulic approaching downward, stable and reliable. 4. E21 can control the movement of ram stroke and backgauge, achieving efficient and highly precise positioning. 5. Wedge compensation on top punch clamping. 6. Simplified top blades clamping with micro-adjustment wedges,for easy operation and high precision. 7. 2…

Products Description TYPE Nominal Force(KN) Worktable Length(mm) Throat Depth(mm) Slider Travel(mm) Power(kw) 63T/3200 630 3200 300 100 5.5 80T/2500 800 2500 320 100 7.5 80T/3200 800 3200 320 100 7.5 80T/4000 800 4000 320 100 7.5 100T/2500 1000 2500 320 120 7.5 100T/3200 1000 3200 320 150 7.5 100T/4000 1000 4000 320 150 7.5 125T/3200 1250 3200 320 150 11 125T/4000 1250 4000 320 150 11 160T/3200 1600 3200 320 200 11 160T/4000 1600 4000 320 200 11 160T/5000 1600 5000 320 200 11 160T/6000 1600 6000 320 200 11 200T/3200 2000 3200 320 200 11 200T/4000 2000 4000 320…

Our standard range of press brakes are available in 40 ton to 1000 ton bending capacity and in bending widths from 1250mm to 7000mm. In addition to this we offer special high tonnage machines, tandem models and many high productivity options.We offer controls from simple 2-axis CNC through to 3D graphical touch screen models with 10 controlled axes. While we specify machines with a range of popular features, all models can be configured to meet individual requirements.Products DescriptionOur range of NC and CNC sheet metal Press Brakes is extensive and of peerless quality. That means the very best machine for…
