metal punching machine

A punch machine is a stamping press. Stamping production is mainly for plates. Through the mold, it can make blanking, punching, forming, deep drawing, trimming, fine blanking, shaping, riveting and extrusion parts, etc., which are widely used in various fields. For example, we use switch sockets, cups, cupboards, dishes, computer cases, and even missile aircraft... There are a lot of accessories that can be produced through molds with a punch. Details Images Specification Item J23-10T J23-16T J23-25T J23-40T J23-63T J23-80T J23-100T J23-125T Nominal Pressure 100KN 160KN 250KN 400KN 630KN 800KN 1000KN 1250KN Slide stroke (Times/min) 145 140 70 55 50…

Products Description 25 Tons Hydraulic Power Press Punching Machines are stronger and more feature packed than any gap frame press on the market today. More steel in the c-section of the frame reduces what is known as angular deflection under full stamping loads. Larger flywheel, higher energy rating point ABDC, connecting rods and ball screws. New cast slide body with digital die height indicator and large flanged upper die adapter plate. Slide guides are taper wedge design like our straight side presses to assure long die life during production runs. The JH21- 200 ton GEN-2 (left) shows our standard I-PRESS…

Main Features: 1.  J23 series Open Eccentric Presses is a general-purpose presses, suitable for forming, blanking, punching, bending and other cold stamping process. 2.  C-frame Casting fuselage,maximum rigidity and minimum deflection for accurate parts and long tool life. body can be tilted, high rigidity and less deformation Compact. Thick plates and large columns provide you with the stable platform you need for your demanding application. 3.  The Machine use Rigid rotated bond clutch rigid and well supported. The clutch gives continuous strokes for mass production. 4.  Crank shaft is made of special alloy steel machined to close accuracy and fitted in…

Products Description J23 series punch press is a suitable open type crank press featuring a left and right open type machine body (i.e. C-shaped machine body). Its steel plate welded body has high shock-absorbing performance.Its novel overall design gives the machine elegant appearance. Its throat has certain depth. The compact structure makes the use convenient and operation safe. The punch press is equipped with a turn-key rigid clutch, a cam band brake and a press-down type safety device. Its working table is open on three sides, so the mold loading and unloading and operation are convenient. The punch press is…
