single phase press brake

Product Description This machine has advanced technology and reliable performance, which makes it ideal equipment for sheet forming. It is widely used in many industries, such as plane, automobile, ship, electronics, machinery and light industry, with high production efficiency. The whole machine is welding constructed up with steel sheets. It has enough strength and toughness. Hydraulic drive can prevent serious over-load accident due to the change of sheet thickness or incorrect position of lower die V slot. Furthermore, it works stably and reliably with easy operation. It also has the functions like inching movement, single movement and continuous movement. Especially…

Product Description Electro hydraulic synchronous CNC bending machine Adhering to the European design concept, it is a new generation of CNC bending machine with simple appearance, practical and efficient, stable and reliable, high cost performance and low failure ratePerformance characteristics 1. The fuselage adopts integral welding and integral processing structure, and the main components of the fuselage are analyzed by ANSYS finite element analysis software, so as to ensure the reliability of the machine tool and the accuracy of the whole machine; 2. The main cylinders on both sides break through the stroke control mode of the traditional mechanical stop…

Products Description TYPE Nominal Force(KN) Worktable Length(mm) Throat Depth(mm) Slider Travel(mm) Power(kw) 63T/3200 630 3200 300 100 5.5 80T/2500 800 2500 320 100 7.5 80T/3200 800 3200 320 100 7.5 80T/4000 800 4000 320 100 7.5 100T/2500 1000 2500 320 120 7.5 100T/3200 1000 3200 320 150 7.5 100T/4000 1000 4000 320 150 7.5 125T/3200 1250 3200 320 150 11 125T/4000 1250 4000 320 150 11 160T/3200 1600 3200 320 200 11 160T/4000 1600 4000 320 200 11 160T/5000 1600 5000 320 200 11 160T/6000 1600 6000 320 200 11 200T/3200 2000 3200 320 200 11 200T/4000 2000 4000 320…

Standard Equipment DELEM DA58T CNC control System Powered Depth Y-axis&Back gauge X-axis DELTA Inverter controlled back gauge HIWIN Ball screws & Polished rod with 0,05mm accuracy. Plate Support Arms Germany Bosch-Rexroth Hydraulic Germany EMB Tubing connector Germany Siemens Main Motor Tele mecanique/Schneider Electrics Hydraulic &Electrical overload protection Top and Bottom Tooling(86°,R0.6mm) Safety Standards(2006/42/EC) SPECIFICATIONS FOR WE67K-160T/3200 HYDRAULIC PRESS BRAKE 1 Max.working length 3200mm 2 Max.bending thickness 5mm 3 Distance between columns 2600mm 4 Stroke(Y-axis) 250mm 5 Throat Depth 400mm 6 Motor Power 22KW 7 Open height 540mm 8 Length x Width x Height 2500x2200x2600 9 Weight 12T Main Features 1.…
